Welded pipe
We supply welded pipes according EN10217-1/6 and EN10217-7 as a service product. In order to be able to supply the complete piping range, we also offer the pipes.
- On request
- Dimensions, weights and wall thickness according EN10220/ DIN EN ISO 1127
- SRL/DRL or fix lengths available
- Available in carbon steel or stainless steel
We deliver welded pipes in the following material grades:
| EN standard |
| Carbon steel |
| P235GH TC1 |
| P265GH |
| 16Mo3 |
| 13CrMo4-5 |
| S355 |
| 11CrMo9-10 |
| Stainless steel |
| 1.4301 / 1.4306+7 / 1.4541 |
| 1.1104 / 1.4404 / 1.4571 |
| 1.4462 (duplex) / 1.4501 (superduplex) |
According to the standard EN10217 welded pipes are separated in:
| DIN standard | EN standard | Material |
| 1626/1628 | EN 10217-1 | Carbon steel |
| 17177 | EN 10217-2 | Carbon steel |
| 17178 | EN 10217-3 | Carbon steel |
| 17174 | EN 10217-4 | Carbon steel |
| EN 10217-5 | Koolstofstaal | |
| EN 10217-6 | Koolstofstaal | |
| 17457 | EN 10217-7 | Roestvaststaal |
Click on one of the PDF logos to start the download.
 |
Schedule sizes |
|
Stock programme |
|
Delivery programme |
